| Size | 7.28″ (W) x 6.77″ (D) x 2.20″ (H) |
| : Weight | 2.62 lbs |
| : Antenna socket | SO-239 |
| : Antenna impedance | 50 ohms |
| : Frequency ranges | from 24.890 Mhz to 24.990 Mhz and from 28.000 Mhz to 29.700 Mhz (continuous scanning) |
| : Power supply (Input Voltage) | 13.8 V |
| : Microphone Up/Down | Activate / Deactivate |
| : Microphone plug | front (6 pins) |
| : Compatible microphone type | Electret , Dynamic |
| : External Vox microphone jack | |
| : External loudspeaker jack | |
| : Public address | |
| : External HP PA socket | |
| : USB socket (front) | 5 V / 2,1 A |
| : Display | LCD multifunction |
| : Dimmer | |
| : Channel display | |
| : Frequencies display | |
| : DC\TEMP | |
| : S-meter | Digital |
| : Modulation modes | AM / FM / USB / LSB |
| : Volume adjustment and ON/OFF | |
| : Squelch | Manual squelch |
| : Automatic Squelch Control (ASC) | |
| : Channel selector | Rotary |
| : F / Menu function key | |
| : Automatic Relay | |
| : Repeater / Relay (only D band) | |
| : Key Beep | |
| : Roger beep | |
| : Key locking | |
| : Tone | |
| : Memory | 4 |
| : Channel Shortcuts | 2 , emergency channel (EMG) programmable |
| : Span | |
| : Dual watch | |
| : Channel Scan | |
| : Scan Skip | |
| : RF Power | |
| : RF Gain | |
| : Mic Gain | |
| : Clarifier | |
| : Talkback | |
| : Hands Free (Vox) | |
| : Automatic SWR meter | |
| : SWR Meter | |
| : SWR Protection | |
| : Voltage Protection | |
| : Echo | |
| : Call / Message | |
| : TOT | |
| : Filter ANL | |
| : Filter NB | |
| : Filter HI-CUT | |
| : NRC | |
| : Noise Gate | |
| : CTCSS | 38 tones |
| : DCS | 104 codes |
| : APM | |
| Frequency allowance | ± 200 Hz |
| :Carrier power | 100 W PEP (AM/USB/LSB) / 50 W (FM) |
| :Power limitation | 4/10W |
| :APM | |
| :Transmission interference | < 4 nW (-54 dBm) |
| :Audio response | 300 Hz to 3 kHz |
| :Emitted power in the adj. channel | < 20 μW |
| :Microphone sensitivity | 3 mV |
| :Drain | 12 Amp |
| :Modulated signal distortion | 2% |
| Max. sensitivity at 20 dB sinad | 0.7 μV – 110 dBm (AM) / 0.35 μV – 116 dBm (FM) / 0.28 μV – 118 dBm (USB/LSB/CW) |
| :Frequency response | 300 Hz to 3 kHz |
| :Adjacent channel selectivity | 60 dB |
| :Maximum audio power | 3 W |
| :Squelch sensitivity | min. 0.2 μV – 120 dBm / max. 1 mV – 47 dBm |
| :Frequency image rejection rate | 60 dB |
| :Intermediate frequency rej. rate | 70 dB |
| :Drain | 400 mA nominal / 600 mA maximum |
El Precio Rondara Los 375€…
